Title says all. Can't believe it was never proposed; if it was, I couldn't find.

Missing that, I have to that programmatically, but it's always a detour:

Should be quite easy to change the property page like e.g:

(6 colors for system booleans, 4 for all others, as known)

Currently in LabVIEW you can have a top-level palette (Programming, Measurement I/O, etc) automatically populate based on .mnu files existing in the folder structure at <LabVIEW>\menus\Categories\.  However you cannot do this with the sub-palettes such as Arrays, File I/O etc.

I propose to allow auto-populating palettes for all LabVIEW palettes so developers can place their own palette within the appropriate LabVIEW palette for their functions.  One example is OpenG and MGI each have a palette of Array functions.  They are currently placed in a top-level OpenG\Array or MGI\Array location.  If we could sync these folders, we could place each of the array palettes under the Programming\Array palettes:

Simply by dropping their corresponding mnu files here:

Thoughts?  Discussion on LAVA that spawned this idea is here.

A Context Help annoyance: when I hover over an enum, it graciously provides a wealth of information about the datatype I have chosen for the enum. So much information, actually, that the information I'm after - the items - are cut off by the window. How about a shorthand data representation?

For most functional blocks on the Front Panel, the wire anchor point is very near the edge of the block (reference this idea for an exploded view of the wire anchor point). This lends itself very well to a trick I use to achieve neat parallel wire routing (until this idea is implemented!😞

Step 1: Wire up a bunch of parallel wires, and you've got a mess!

Step 2: Grab one of the functions, and drag it all the way up and down so that the parallel wires all bend along the same line

Step 3: Grab the wires one at a time, and using Shift+Arrow Left or Right and distribute so that the vertical wire runs are evenly spaced

Here's the problem: Bundle by Name, Unbundle by Name, Property/Invoke Nodes, Local Variables etc. have the "wire anchor point" in the center of the node. This makes the above trick difficult, and it also presents more problems:

Frame 1 shows erratic spacing of tunnels, and a highlighted wire that lands in the center of the large Unbundle by Name. I have drawn a red line that shows the center of the wire run as currently implemented, and the green line shows where I propose the wires should bend. Frame 2 shows what you see when check "Hide Full Names": the wire bends are clearly evident and easy to fix, as shown in Frame 3.

Another problem is "what you see is (maybe or maybe not) what you get":

The three tunnels appear to be wired to 6, 7, and 8, but indeed they are actually wired to 1, 5, and 7.

In a nutshell: When the location of a wire bend is calculated, it should bend halfway between the edges of two nodes. This could be accomplished by placing the wire anchor point at the edge of the node instead of the center of the node.

Picture says it all.

I am not allergic to Kudos, in fact I love Kudos.

 Make your LabVIEW experience more CONVENIENT.

In 2014 the Clear errors VI now accepts a single error which can be cleared.  This is nice but when I heard NI was implementing their own filter errors, I assumed they would do it in a similar way to the OpenG Filter Errors VI, which accepts a scalar, or an array of error codes to filter.

In addition to this I think it would be helpful if this Clear Errors also accepts the error data type for errors to filter, or an array of errors to filter.  That way the Error Ring can be used to help readability of the block diagram showing the error that is being cleared.
